Plasma Surface Treatment & Measurement

Professional surface treatment and measurement solutions for semiconductor, EV battery, display, and consumer electronics. Atmospheric and vacuum plasma, ultrasonic dry cleaning, and contact angle measurement.

Sindin official logo
Sindin USC Cleaning
Dongguan, China · National High-Tech Enterprise
2012
Founded
179+
Patents
18,000 m²
Facility

Product Portfolio

Plasma Treatment Systems

Atmospheric Plasma

Inline surface cleaning, activation, and coating at atmospheric pressure. Integrates directly into production lines for bonding, plating, taping, coating, printing, and molding.

  • Non-contact processing
  • Inline integration
  • Multiple head configs
Vacuum Plasma

Chamber-based plasma for batch processing. High uniformity across complex 3D surfaces. For semiconductor, advanced packaging, and precision components.

  • Batch processing
  • High uniformity
  • 3D surface treatment
DBD & Microwave Plasma

Specialized plasma for semiconductor, display, and advanced materials. DBD for large-area treatment, microwave for high-density processing.

  • Semiconductor grade
  • Large-area DBD
  • High-density microwave

Cleaning & Measurement

USC Ultrasonic Dry Cleaning

Surface particle removal using ultrasonic vibration and vacuum. No chemicals. Horizontal, vertical, inline configs. For FPD glass, silicon, film, metal frames.

  • Chemical-free
  • Cleanroom compatible
  • Inline / standalone
Contact Angle Tester

Precision surface wettability measurement for QC of plasma treatment. Measures contact angle to verify surface energy and treatment effectiveness.

  • Treatment QC
  • Surface energy analysis
  • GB/T 30693 standard
RTP Rapid Thermal Processing

High-temperature rapid thermal processing for semiconductor wafers. Precise temperature control for annealing, oxidation, and diffusion.

  • Wafer processing
  • Rapid heating/cooling
  • Precise temp control

Industries Served

Consumer
Electronics

Automotive
& EV Battery

FPD Display

Semiconductor

LED

Photovoltaic

Trusted by: Huawei, BYD, CATL, Foxconn, BOE, TSMC, TDK, NXP, ST, Jabil

CE
Certified
ISO
9001
179+
Patents
40%
R&D Staff

Need Plasma Treatment Equipment?

Contact us for product selection, process consulting, and quotation.
